CONTROLS & FUNCTIONS
6
5. Bass Boost Switch
6. BRIDGED
4. Low Level OUT RCA jacks
LINE OUT
L-CH L-CH R-CHR-CH
INPUTS
EGA900D / EGA1400D / EGA1700D
OFF ON
BASS
BOOST
EGA900D / EGA1400D / EGA1700D
CONNECTION
BRIDGED
MASTER SLAVE
EGA900D / EGA1400D / EGA1700D
The LINE OUT allows you to build multiple amplifier systems without having to use splitter cords
to distribute the signal. Now it is simply a matter of bringing one set of RCAS into the first amplifier,
then using the line out RCA jacks as the feed to the next amplifier.
By using the bass boost function, bass notes at 35Hz - 80Hz are emphasized as much as 10dB.
