7. B-Terminal (Chassis ground)
8. B+ Terminal (Battery positive)
9. Remote Power On
Controls & Functions
GND REM+12V
TOP FRONT
FRONT
GND REM+12V
TOP
FRONT
GND REM+12V
TOP
EGA900D / EGA1400D / EGA1700D
EGA900D / EGA1400D / EGA1700D
EGA900D / EGA1400D / EGA1700D
CONTROLS & FUNCTIONS
7
To avoid unwanted ignition noise caused by ground loops, it is essential that the Amplifier be
grounded to a clean, bare, metal surface of the vehicles chassis.
Note : GROUND WIRE SHOULD NOT BE EXTENDED MORE THAN 3 FT (1 METER).
Due to the power requirements of the Amplifier, this connection should be made directly to the
positive(+) terminal of battery. For safety measure, install an in-line fuse Holder (not included)
as close to the battery positive(+) terminal as possible with an ampere rating not to exceed
total value of fuses in Amp.
