B622-335 LTE CPE
Product Description
2 Technical Specifications
Issue01 (2021-07-22)
Copyright © SOYEA TECHNOLOGY CO.,
LTD.
7
Item
Description
AC/DC
power supply

AC (input): 100V-240V 50Hz/60Hz

DC (output): 12V/2A
Dimensions
(Maximum)
240 mm (Width) x 155 mm (High) x78 mm (Deep)
Weight
< 440g (excluding the power adapter)
Temperature

Working temperature: 0°C to 40°C

Storage temperature: -20°C to +70°C
Humidity
5% – 95% (non-condensing)
Certification/Co
mpliance
CE
Wi-Fi
ERP
WEEE
ROHS
REACH
Table 2-2 LTE CA combination
Item
Description
Band combination
LTE
DL
MIMO
CA_3C
2+2
CA_7C
2+2
CA_38C
2+2
CA_40C
2+2
CA_41C
2+2
CA_42C
2+2
2.2 Antenna Specifications
2.2.1 Build-in LTE Antenna
Table 2-3 LTE antenna specifications
Item
Description
Frequency
LTE

B1: UL 1920-1980 MHz, DL 2110-2170 MHz

B3: 1710-1785 MHz, DL 1805-1880 MHz

B7: UL 2500–2570 MHz, DL 2620–2690 MHz

B8: UL 880-915 MHz, DL 925-960 MHz
