4 System Structure and Scenario
Constraints
4.1 System Architecture
Figure 4-1 System structure
The following describes the modules shown in Figure 4-1.

LTE access function: The B622-335 adopts the LTE access technology at the WAN side.

Wired broadband access: Wired WAN ports are used on the WAN side, and PPPoE and
DHCP access are supported.

LAN access function: One 10/100/1000 Mbps high-speed Ethernet ports are provided at
the LAN side. The B622-335 provides the switching function for local networking and
sharing of the broadband network when it is connected to terminal devices.

AP function: An 802.11b/g/n/a/ac/ax -compliant Wi-Fi AP interface is provided for
wireless networking at home. The interface is compliant with the IEEE
802.11b/g/n/a/ac/ax standard and the WPA/WPA2-PSK, WPA2-PSK, WPA3-SAE,
WPA2-PSK/WPA3-SAE security authentication mechanisms.

DHCP/DNS: The DHCP server dynamically allocates IP addresses to PCs.

Web-based management: You can configure the B622-335 and modify and view the
configuration of the B622-335.
