(2) Chipset Cooling Fan
Some chipset also feature a cooling fan. This Motherboard features a
CHIPFAN connector to provide 12V power to the chipset fan. Connect the
cable from the chipset fan to the CHIPFAN 3-pin connector. Install
according to the following pin assignment:
Note:
CPUFAN must be installed for this Motherboard, CHIPFAN is
optional.
5. CD Line-in (CDIN1)
This Motherboard provides two CD-Line in connectors. Please connect the
4-pin audio cable from your CD-ROM drive to either CDIN1. (It fits in
only one, depending on the cable that came with your CD-ROM drive)
Please install according to the following pin assignment:
CD-IN: CDIN1
123 4
Right
Left
GND
GND
NC
12V
GND1
3
2
Chipset Cooling Fan
CHIPFAN Pin Assignment
