– 55 –
SIM Inverter Monobloc Air-to-Water Heat Pump
NO Part Number Description Wiring Diagram Callout SIM -036 SIM -060
1
45W33-WG1194-01
Compressor M1
X
45W33-WG1259-01 X
2
45W41-WG1195-01
Chassis base plate
X
45W41-WG1195-02 X
3
45W41-WG1196-01
Front access panel
X
45W41-WG1196-02 X
4 45W19-WG1197-01 Handle, access panel X X
5
45W43-WG1198-01
Fan guard
X
45W43-WG1198-02 X
6
45W41-WG1199-01
Left coil guard
X
45W41-WG1199-02 X
7 45W34-WG1200-01 Fan Blade X X
8
45W41-WG1201-01
Fan Panel
X
45W41-WG1201-02 X
9
45W31-WG1202-01
Fan Motor
M2 X
45W31-WG1260-01 M2, M3 X
10
45W41-WG1203-01
Fan Support
X
45W41-WG1203-02 X
11
45W41-WG1204-01
Rear coil guard
X
45W41-WG1204-02 X
12
45W41-WG1205-01
Intermediate plate
X
45W41-WG1205-02 X
13
45W41-WG1206-01
Cover, Electrical Box
X
45W41-WG1206-02 X
14
45W41-WG1207-01
Cover, top
X
45W41-WG1207-02 X
15
45W50-WG1208-01
Coil, nned tube
X
45W09-WG1261-01 X
16
45W50-WG1209-01
Heat exchanger, refrigerant to water
X
45W50-WG1262-01 X
17
45W40-WG1210-01
Manifold, Water outlet
X
45W40-WG1210-03 X
18 45W11-WG1211-01 Flow switch X X
19 45W11-WG1212-01 Pressure sensor(0~45bar 0-652 PSI)
X1 X
X2 X
20 45W11-WG1212-02 Pressure sensor(0~20bar 0-290 PSI)
X2 X
X3 X
21 45W27-WG1214-01 Filter, refrigerant X X
22 45W05-WG1216-01 Cover, power inlet X X
23
45W41-WG1217-01
Panel, plumbing inlet
X
45W41-WG1217-02 X
24
45W41-WG1213-01
Panel, rear
X
45W41-WG1213-02 X
25
45W11-WG1218-02
Pressure switch, Low limit (.30 Mpa/.15 Mpa) S3
X
45W11-WG1218-01 X
26
45W11-WG1218-01
Pressure Switch, High limit, (3.2 Mpa/4.2 Mpa) S2
X
45W11-WG1218-02 X
27
45W28-WG1219-01
EEV V2
X
45W28-WG1219-02 X
28
45W28-WG1220-01
Reversing Valve V1
X
45W28-WG1220-02 X
29
45W41-WG1221-01
Support, inside heat exchanger
X
45W41-WG1221-02 X
30 45W40-WG1210-02 Connector, 1" NPT X
31 45W40-WG1215-01 ACCESS VALVE, SAE 1/4", SIM-036 TO -060 X X
32 45W40-WG1215-02 ACCESS VALVE, SAE 5/16", SIM-036 TO -060 X X
33 45W40-WG1215-03 CAP ACCESS VALVE, SAE 5/16", SIM-036 TO -060 X X
34
45W41-WG1222-01
Control box
X
45W41-WG1222-02 X
Replacement Parts
