– 56 –
SIM Inverter Monobloc Air-to-Water Heat Pump
Replacement Parts (continued)
NO Part Number Description Wiring Diagram Callout SIM -036 SIM -060
35
45451-WG1223-01 Panel, electrical components X
45451-WG1223-02 Plate in electrical control box X
36 45W09-WG1224-01 2-pole terminal TS, TS3 X X
37 45W09-WG1225-01 4-pole terminal (power supply) TS1 X X
38 45W10-WG1227-01 Relay K2, K9, K12, K13 X X
39
45W09-WG1228-01
EMI Reactor L1
X
45W09-WG1228-02 X
40 45W09-WG1229-01 Fan speed module IC3 X X
41
45W09-WG1230-01
EMI Filter IC4
X
45W09-WG1230-02 X
42
45W09-WG1231-01
Inverter, Compressor drive IC2
X
45W09-WG1231-02 X
43 45W09-WG1232-01 Control Board IC1 X X
44 45W09-WG1233-01 Remote touchscreen display VT1 X X
45 45W09-WG1409-01 Cap, terminal End X X
46 45W09-WG1358-01 Terminal, Feed Through, 1pole X X
47 45W09-WG1408-01 Terminal, Feed Through, 2pole X X
48 45W09-WG1359-01 Terminal, Feed Through, 1pole, anged X X
N/A 45R20000-3242 Temperature Sensor, 5k NTC T1, T2, T4, T5, T6 X X
N/A 45W09-WG1413-01 Temperature Sensor, 50k NTC T3 X X
N/A 45W09-WG1415-01 PTC Thermistor, compressor start PTC X
