ASSEMBLEASSEMBLE
5g 5g
Install air pumps onto machine:
• Insert at an angle
• While pushing air pump in, slightly rotate back and
forth until the gear engages the air pump drive shaft
• Push in and rotate counter-clockwise to lock in place
5h 5h
Assemble air tubes; each air tube has O-
rings (3), connectors (2), and check valve
(1); lubricate O-ring areas
5. Assemble and
install air pumps
If machine will go unused, install air tubes into hopper,
but do not connect to air pumps; otherwise, set air
tubes aside until after machine has been primed
5i
Spaceman USA Soft Serve Pump Training
rev042219
