SpacePak ESP-J - Figure 2.6: Horizontal Air Flow Unit Installation

9
FIGURE 2.6: HORIZONTAL AIR FLOW UNIT INSTALLATION
14 Ft. MAXIMUM FLEXIBLE
RETURN DUCT
FAN COIL UNIT
SUPPORT
RETURN AIR BOX
90°
90°
2 Ft.
MAX.
PLATFORM (FIELD ERECTED
AS SHOWN IN STEP 4)
SUPPORT
SUPPLY AIR
FIGURE 2.7: TYPICAL INSTALLATION WITHOUT DUCTED RETURN
