ATTACH SHAFTS TO BASE
Use diagrams on these pages for location
of each shaft. Push shaft into holes on base
until sturdy.
Now is a good time to attach the See-Saw
Arms as shown.
Attach Shaft Connector
between shafts D and E.
a
105 cm
b
26 cm
c
G
Step 1: Measure each section and mark the
cutting point with a pen.
Step 2: Cut each section according to your
measurement. Make sure to cut at a 90° angle.
Tip: To help avoid do-overs and using too
much rail, cut generously (slightly longer than
required) to begin with. You can always cut a
long rail shorter.
(Illustration of rail lengths is 16.5% of actual size).
CUT THE RAIL TO SIZE
