Step 2: Attach each Arm and See-Saw Arm as shown in step 1 with the orientation
and location shown here. In later steps the letter of each Shaft and number of each
Arm will guide in the installation of the Rails. Illustration is approximately 51% of
actual size. All Shaft measurements are in Millimeters.
