PROGRAMMING/OPERATION
INSTRUCTIONS
POWER ASSIST / POWERPRO
®
WITH TOUCHPAD CONTROL
The following procedure allows the user to program the TouchPad
Control with their own 4-digit code. Upon initial power-up the
TouchPad Control code is set to 1 2 3 4.
To change code.
1. Press the "
#
" key, then press the "*" key . The green L.E.D. will begin
to blink.
2. Dial in the present code within the allotted 10 seconds. The red L.E.D.
will begin to blink.
3. Dial in the new code within the allotted 10 seconds.
4. The solid green L.E.D. will return.
Note: Key press during code set will sound a beeper.
Note: To verify that the new code has been accepted; with the reset light blinking, dial
in the code again. The red L.E.D. should glow steady for 3 seconds and then go out.
Operation of the system with close left configuration.
1. Begin with the carriages packed to the left.
2. Select an aisle and enter the appropriate code on the TouchPad.
3. Carriage(s) will move right to open the aisle to the left of the TouchPad
which has been used.
4. Upon exiting the open aisle the operator goes to the far right carriage and
presses the “Close button”.
5. The carriage(s) will move left to pack all carriages to the left.
6. The carriages are now configured for the next move request.
Operation of the system with close right configuration.
1. Begin with the carriages packed to the right.
2. Select an aisle and enter the appropriate code on the TouchPad.
3. Carriage(s) will move left to open the aisle to the right of the TouchPad
which has been used.
4. Upon exiting the open aisle the operator goes to the far left carriage and
presses the “Close button”.
5. The carriage(s) will move right to pack all carriages to the right.
6. The carriages are now configured for the next move request.
OP-0204
