Assemble the Base
16
C
INSTALL THE OVAL POLE ONTO THE BASE
5. Rotate the non-secured ends of
the base struts (3) to align with the
mounting holes in the base.
6. Secure the ends of the base struts
(3) to the wheel brackets (4), with
bolts (18) and washers (9).
IMPORTANT
DO NOT TIGHTEN COMPLETELY.
#18
#9
#4
#3
7. Secure the cover (2) to the base
struts (3) using bolts (19) and nuts
(20).
IMPORTANT
Tighten all components completely.
#19
#2
#3
#20
To Next Page
