Assemble the Backboard
20
Assemble the Backboard
Required Parts: Completed Backboard Assembly:
• Kit 4
• Kit 6
• Wrenches and/or
Socket Wrenches
• Socket Wrench Extension
• Phillips Screwdriver
• Sawhorse
WARNING
TWO PEOPLE ARE REQUIRED FOR THIS PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS
INJURY AND/OR PROPERTY DAMAGE.
E
ATTACH THE ELEVATOR TUBE ASSEMBLY
1. Securely rest the assembly on a sawhorse. Identify the elevator tubes (31 & 32).
#31
#32
