SPALDING AA6A1355 - Assemble the Goal

Assemble the Goal
27
Assemble the Goal
Required Parts: Completed Goal Assembly:
• Kit 5
• Wrenches and/or
Socket Wrenches
• Socket Wrench Extension
• Phillips Screwdriver
G
ASSEMBLE THE GOAL
1. Insert the t-bolt (52) through the slam jam bracket (47).
2. Secure the slam jam bracket (47) to the backboard using the bolts (57) and nuts (20).
#52
#57
#47
#20
