Assemble the Goal
28
G
ASSEMBLE THE GOAL
3. Fit the rim (45) securely into the slam jam bracket (47). Allow the t-bolt (52) to slip through the
center hole in the rim (45).
#45
#47
#52
4. Install the reinforcement bracket (54) onto the t-bolt (52).
#54
#52
5. Install the spring (55) onto the t-bolt (52).
#55
#52
