SPALDING AA6A1355 - Page 29

Assemble the Goal
29
G
ASSEMBLE THE GOAL
6. Install the special nut (53) and washer (56) onto the t-bolt (52).
#53
#56
#52
7. Tighten the nut (53) until 1/8" (3mm) of
the bolt threads onto the exposed end of
the t-bolt (52).
#56
#52
#55
#53
1/8"
(3mm)
8. Attach the cover (46) to the rim (45) using
the cover screws (58).
#46
#64
#45
#58
