Assemble the Goal
30
G
ASSEMBLE THE GOAL
9. Thread the net (51) onto the rim (45).
#45
#45
#45
#45
#51
#51
#51
#51
10. Apply the Height Adjustment and Moving
Label (50) to the front of the pole, where it
is clearly visible.
#50
11. While holding the handle, remove the pin
(24).
12. Move the elevator up or down to the
desired height.
13. Replace the pin (24) at full length to lock
the system at the desired height.
WARNING
DO NOT ALLOW CHILDREN TO ADJUST THE
HEIGHT.
#24
