SPALDING AA6A1355 - Page 35

Parts List
35
Item Qty Part No. Description Item Qty Part No. Description
1 1 600335 Base, Plastic, Black 34 1 204838 Spring, Counter Balance
2 1 60033701 Ball Return, Plastic, Black 35 1 600362 Cap, Plastic, On Top Pole
3 2 908184 Strut, Steel Tube, Black 36 1 209096
Bolt, Hex Head,
1/2-13x3.96L(1.25)
4 2 108183 Wheel Bracket, Steel 37 4 209001 Bolt, Hex Head, 1/2-13x7.75L
5 2 266200 Wheel, 4 inches, Plastic, Black 38 2 209101 Bolt, Hex Head, 3/8-16x5.375L
6 2 10818201 Rod, Axle 39 5 206340 Nut, Hex Nylock, 1/2-13
7 4 207550 Pushnut, 7/16 Shaft Diameter 40 1 208499 Spacer, Plastic, 0.75ODx3.25L
8 2 204962 Bolt, Hex Head, 5/16-18x0.625L 41 2 204620 Spacer, Plastic, 0.73ODx1.70L
9 6 203218 Washer, Flat, 5/16 42 4 201642 Spacer, Plastic, 0.75ODx0.625L
10 1 901390 Bottom Pole, Black 43 2 203063 Nut, Hex Nylock, 3/8-16
11 1 901790 Middle Pole, Black 44 4 209099 Spacer, Plastic, 0.38IDx0.527L
12 1 901789 Top Pole, Black 45 1 Rim
13 1 108181 Plate, Bottom Pole Mounting
46
1 200503 Cover, Black
14 2 203679 Bolt, Hex Head, 3/8-16x2L 1 200504 Cover, Red
15 1 202662 Bolt, Hex Head, 5/16-18x4-1/2L 47 1 900033 Bracket, Slam Jam, Square, Black
16 1 203099 Nut, Nylock, 5/16-18 48 1 203617 Cap, For Base
17 2 208251 Washer, Flat, Plastic, Black 49 6 206303 Washer, Flat, 1/4
18 2 203156 Bolt, Hex Head, 5/16-18x1.00L
50
1 500072
Label, Height Adjustment and
Moving
19 6 208505 Carriage Bolt, 5/16-18x1.50L 1 FR500072
Label, Height Adjustment and
Moving, French
20 12 203100 Nut, Hex Flange, 5/16-18 51 1 Net
21 1 200516 Cover, Bolt End, Vinyl, Black 52 1 206048 Bolt, Tee, 3/8-16, 3.25L
22 1 702657 Lift Bracket, Pre-assembly 53 1 203795 Nut, Special, Long, 3/8-16
23 1 702660 Handle, Plastic, Pre-assembly 54 1 200318
Bracket, Reinforcement, Slam
Jam
24 1 204850 Pin, Locking 55 1 208760 Spring, On Rim
25 1 204853 Lanyard, Black Coil 56 1 203470 Washer, Flat, 1.5OD
26 1 901607 Tube for Height Adjustment, Black 57 4 208892
Bolt, Hex Flange,
5/16-18x1.625L
