SPALDING E6A994 - Page 11

07/08 ID# M6611742
11
WHEEL ASSEMBLY - HARDWARE IDENTIFIER KIT #1 Shown Full Scale
#13 (4)
#9 (2)
PARTS LIST - KIT #1
Item Qty. Part No. Description
7 2 108183 Wheel Bracket
8 2 266200 Wheel, 4 Inch
9 2 10818201 Rod, Axle
13 4 207550 Pushnut, 7/16 Shaft Diameter
18 2 204962 Bolt, Hex Head, 5/16-18 x .625 Long
51 2 203218 Washer, Flat, 5/16
#51 (2)
#18 (2)
#8 (2)
#7 (2)
KIT #1
Not Shown Full Scale
