ATTACH THE BACKBOARD (ELEVATOR) - HARDWARE IDENTIFIER - KIT #5
Shown Full Scale
Item Qty. Part No. Description
11 2 203063 Nylon Insert Lock Nut, 3/8-16
26 4 208891 Spacer, .380 I.D. x .67 Long
27 2 208890 Bolt, Hex Head, 3/8-16 x 5.625 Long
29 4 206244 Bolt, Hex Head, 1/2-13 x 8 Long
30 4 201642 Spacer, Plastic, .530 I.D. x .625 Long
31 5 206340 Lock Nut, Hex 1/2-13
33 1 204838 Spring, Counter Balance
36 2 201682 Spacer, .530 I.D. x 1.875
37 2 908017 Plate, Triangle, Silver
900867 Plate, Triangle, Black
38 1 600137 Cap, Pole Top
40 1 202605 Bolt, Hex, 1/2-13 x 4.25 Long
48 1 206089 Spacer, Plastic, .530 I.D. x 3.5 Long
66 1 220579 Spacer, Metal, .51 I.D. x 5.0 Long
ATTACH THE BACKBOARD - PARTS LIST - KIT #5
#26 (4)
KIT #5
#37 (2)
#38 (1)
#31 (5)
#30 (4)
#36 (2)
#48 (1)
#40 (1)
#27 (2)
#66 (1)
Not Shown Full Scale
