20.
Assemble upper elevator tubes (35) to backboard using bolt (27), plastic spacers (26),
and nut (11) as shown.
26
27
35
26
35
11
WARNING!
USE EYE PROTECTION WHEN
INSTALLING SPRINGS.
WARNING!
TWO PEOPLE REQUIRED FOR THIS
PROCEDURE. FAILURE TO FOLLOW THIS
WARNING COULD RESULT IN SERIOUS INJURY
AND/OR PROPERTY DAMAGE.
32
