IMPORTANT!
POSITION SPRING (33) AGAINST
ELEVATOR TUBES AS SHOWN.
33
Insert bolt (29) through left side upper elevator tube (35), and into spacer (66) then stretch the
spring (33) over spacer (66). Insert bolt (29) through right side upper elevator tube (35) and
secure with nut (31).
21.
WARNING!
USE EYE PROTECTION WHEN
INSTALLING SPRINGS.
31
35
29
35
33
66
