SPALDING E6A994 - Page 34

34
ID# M6611742 07/08
#39 (2)
#58 (1)
#57 (1)
#55 (1)
ATTACH THE GOAL- HARDWARE IDENTIFIER - KIT #6 Shown Full Scale
KIT #6
ATTACH THE GOAL - PARTS LIST - KIT #6
Item Qty. Part No. Description
39 2 200520 Screw, #8 x 3/4 Long
41 1 203617 Cap, Base
55 1 200318 Bracket, Reinforcement, Slam Jam
56 1 208760 Spring, Rim
57 1 203795 Nut, Special, 3/8-16
58 1 203470 Washer, Flat, 1.5 O.D.
64 1 200503 Cover, Black OR
200504 Cover, Red
203617
#41 (1)
#64 (1)
#56 (1)
Not Shown Full Scale
