Hardware Overview
Listed below are some of the characteristics and operating ranges of the AK9753 Human Presence Sensor.
Characteristic Range
Operating Voltage 3.3V
Operating Temperature -30°C to 85°C
Current Consumption 10 μA (typ.), 100 μA (max) (5V)
Spectral Sensitivity 5-7 μm (5V)
Detection Range 3 m (5V)
Temperature Sensor Range -10° to 60°C
Pins
Pin Description Direction
GND Ground In
3.3V Power In
SDA Data In
SCL Clock In
INT Interrupt, goes high when data is ready. After data is read, the pin pulls
low
Out
