MAINTENANCE 29
shown below. Release the Clamp Lever. Ensure that the
middle section of the Travel Guard (A) is held securely in
the Skate Clamp.
5 INSTALL THE TRAVEL SCREW
Install the Travel Screw (A) into the Screw Slot (B) by turning
clockwise until hand-tight.
6 REMOVE THE CLAMP LEVER
Slide the Clamp Lever (A) o of the Lever Dock.
A
A
When setting up the Sparx Sharpener after travel, wipe
down the Grinding Ring Shaft’s face and threaded arbor
to remove any unwanted steel shavings that may have
gathered during transit. This will ensure a proper fit
between the Grinding Ring Shaft and the Grinding Ring.
A
B
