19
MT8 FOUR SPEAKER SPECIFICATIONS
SpeakerType: 3-WayIn-Wall
Woofer: 8" Aluminum / Magnesium Cone with Phasing Dome
Midrange: 2
1
2"Aluminum/MagnesiumDomeUni-Pivot
Tweeter: 1"Aluminum/MagnesiumDomeUni-Pivot
Impedance: 8/6/4 Ohms Depending on Button Settings
Sensitivity: 90dB 1W/1m
Frequency Adjustments: Front-Mounted3Position±3dBBass,
Midrange and Treble Adjustment Buttons
FrequencyResponse: 38Hz-20kHz±2dB
PowerRecommendations: 5-200watts(undistorted)
Dimensions: 16
5
8"(H) x 10
5
8"(W) x 3
3
4"(D)
Wall Cut Out: 15
1
8"(H) x 9
1
8"(W)
In our attempt to constantly improve our products, features and specifications are subject to
change without notice
CUSTOMER ASSISTANCE
If you have any questions regarding the MT8 Three, MT8 Four or any other
SpeakerCraft product, please contact your local Authorized SpeakerCraft dealer, or
youmaycontactSpeakerCrafttoll-freeat1-800-448-0976forimmediatecustomer
assistance. We are available to assist you every weekday, except holidays, between the
hours of 7:00 a.m. and 5:00 p.m. PST.
