9
INSTALLATION PREPARATION
New Construction
When installing the MT8 into a newly built wall, please follow these instructions carefully:
1. Determine Placement
Determine where in the wall the speakers will be placed, using the recommendations
under “SPEAKER PLACEMENT”onpages6-7.Paycarefulattentiontothesectionon
avoiding obstructions.
2. Mount InstaLLock
Bracket
Forbestresults,mounttheSpeakerCraftInstaLLock
New Construction Bracket for
theMT8(PartNo. BKT90685)followingtheinstructionsincludedwiththebracket.
(See Figure 3)
3. AcoustaCell
Considerations
While mounting the AcoustaCell
system may be done at this time, it is not neces-
sary. The system is designed to mount quickly and easily at the time of final speaker
installation, using the instructions under “ACOUSTACELL
INSTALLATION” on page
12. The AcoustaCell
wingsontheMT8InstaLLock
Bracket will assure that the
AcoustaCell
fits exactly into place. AcoustaCell
should only be mounted at this time
if there is an obstruction that would prevent the proper placement at the time of
final installation.
4. The Location is Ready for Drywall
The bracket provides a stable opening around which the drywall installer can
cut out an opening, providing a perfect location for installation of the MT8 and
AcoustaCell
system. (See Figure 4)
5. Proceed to page 12, “ACOUSTACELL
INSTALLATION”.
Figure 3 Figure 4
