AUDIO SECTIONS
Rated Power/Channel 30 Watts, 20 Hz to 20 kHz
(RMS, 2 channels driven into 8 Ohms)
THD (at rated power) < 0.7 %
Power/Channel 45 Watts @ 1 kHz
(RMS, 2 channels driven into 4 Ohms)
Input Sensitivity 300 mV, VC
(For rated power @ max VC) 2.8 V, NVC
Input Impedance (Source Inputs) > 22 K Ohms
Input Overload (Source Inputs) 2.5 V
Output Voltage @ Pre-Outs 1.7 V, VC setting (max)
(w/300 mV @ source inputs) 810 mV, NVC setting
Output Impedance (Pre-outs) < 300 Ohms
Frequency Response 20 Hz to 20 kHz +/- 1.5 dB
(1 Watt @ 8 Ohms)
Channel Separation > 50 dB @ 10 kHz
Crosstalk Between Sources > 65 dB @ 10 kHz
S/N Ratio (Re: Rated output, > 95 dB (VC 20dB below
IEC A, source inputs shorted) FCW)
Bass Control Range +/- 10 dB @ 100 Hz
Treble Control Range +/- 10 dB @ 10 kHz
VIDEO SECTIONS
Bandwidth 10Hz to 6MHz +/- 1dB
(Outputs 75 Ohms Terminated)
Input/Output Levels 1.0V p-p +/- 5%
(Outputs 75 Ohms Terminated)
CONTROL SECTIONS
Contact Closures (dry) 2A, 30 VAC/DC max
Phone Page In Audio Line Level, > 22k Ohm
Voltage/Impedance
Video Page In 1.0V p-p 75 Ohm
Doorbell In 1 & 2, 3V to 10 mA @ 12 VDC/AC
30V AC or DC
Common IR Out – HI 9V Active High, 82 Ohms
(High Power) (110 mA Peak)
– LO (Emitter power) 9V Active High, 670 Ohms
(13 mA Peak)
Zone IR Outs – 9.2V Active High, 620
Voltage/Impedance Ohms (13 mA Peak)
Source IR Outs (and loop) – 11.5 V Active High, 390
voltage/impedance Ohms (29 mA Peak)
Common Status Out (0 to 12 VDC) 9.5 V @ 100 mA
GENERAL
Power Consumption 55 Watts
No Signal (idle)
At 1/8 Rated Power 125 Watts
(3.75 Watts/Channel)
Line Ratings (N.A. Version) 120 VAC, 2.0A
Rear Panel Fuse T5AL 250V
Dimensions 17” (432mm) W x *5-1⁄4”
(133mm) H x 14-3⁄4” (375mm) D
*5-3⁄4” (146mm) H, includ-ing feet
Weight 23 lbs (10.5 kg)
MZC-66 SPECIFICATIONS
LIT13166
