24
www.SpeakerCraft.com
CONFIGURATION AND SETUP TOOL
EQUALIZATION MAIN SELECTION
Choose the Equalization main selection and the Manual EQ Presets page is
displayed. The Room EQ sub selection is also displayed for selection and
conguration.
EQUALIZATION MAIN SELECTION –
ROOM EQ PRESETS
Choose the Room EQ Presets sub-selection and the Room EQ Presets page
is displayed. All 16 channels are listed with their names and currently selected
Room EQ Preset shown to the left.
Note: Even numbered channels are listed inactive if their adjacent odd
numbered channel is set to 100 watts (e.g. when channel 15 is set to 100 watts,
channel 16 is listed as inactive).
1. Use the pull down list of available Room EQ Presets to assign a different
preset to any channel (Flat, Small, Large or Outdoor).
2. Select Save to save Room EQ Presets to the amplier’s memory.
FIGURE 13
