SpeakerCraft SC16-50 User Manual

32
www.SpeakerCraft.com
INPUT
SPEAKER OUT
SPEAKER OUT
LINE OUT
INPUT
LINE OUT
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
1 2 3 4 5 6 7 8
8
9
9
10
10
11
11
12
12
13
13
14
14
15
15
16
9 10 11 12 13 14 15 16
16
100-120 / 220-240 V~
50 / 60 Hz, 1000W
Fuse: 100-120V: T15AL, 250V
220-240V: T10AL, 250V
This Class B digital apparatus
complies with Canadian
ICES-003.
Cet appareil numérique de la
classe B est conforme à la
norme NMB-003 du Canada.
CAUTION: replace only with
same type and rating of fuse.
ATTENTION: remplacer
uniquement avec le même
type et calibre du fusible.
RESET
TRIGGER
IN
OUT
CLASS 2 WIRING
CLASS 2 WIRING
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) this device may not cause
harmful interference, and (2) this device
must accept any interference received,
including interference that may cause
undesired operation.
Minimum impedance:
8 Ω (50W mode)
4 Ω (100W mode)
Serial No.
Z619
SC16 -50
Multi-Channel
Amplifier
Front panel “Master Power”
switch turns off the entire
amplier, including the
Turn-On circuitry
Power LED illuminates to
conrm the amplier is
connected to a live AC power
outlet and that the master
power switch is on.
Banana binding posts for
speaker connections
Factory Default
Reset Switch3.5 mm Jack for
3-24V AC/DC Trigger Output
