SpeakerCraft SC16-50 User Manual

33
SpeakerCraft – 1-800-472-5555 – 1-707-778-5733
16 CHANNEL, FULLY CONFIGURABLE POWER AMPLIFIERS
INPUT
SPEAKER OUT
SPEAKER OUT
LINE OUT
INPUT
LINE OUT
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
1 2 3 4 5 6 7 8
8
9
9
10
10
11
11
12
12
13
13
14
14
15
15
16
9 10 11 12 13 14 15 16
16
100-120 / 220-240 V~
50 / 60 Hz, 1000W
Fuse: 100-120V: T15AL, 250V
220-240V: T10AL, 250V
This Class B digital apparatus
complies with Canadian
ICES-003.
Cet appareil numérique de la
classe B est conforme à la
norme NMB-003 du Canada.
CAUTION: replace only with
same type and rating of fuse.
ATTENTION: remplacer
uniquement avec le même
type et calibre du fusible.
RESET
TRIGGER
IN
OUT
CLASS 2 WIRING
CLASS 2 WIRING
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) this device may not cause
harmful interference, and (2) this device
must accept any interference received,
including interference that may cause
undesired operation.
Minimum impedance:
8 Ω (50W mode)
4 Ω (100W mode)
Serial No.
Z619
SC16 -50
Multi-Channel
Amplifier
Bus Matrix™ Input Gold
Plated RCA Jacks
RJ-45 Ethernet
TCP/IP Connection
Removable 3-prong
16 gauge 6’ AC power cord.
Cascade Audio Output
Gold Plated RCA Jacks
Removable feet for
rack mounting
Bicolor Status LEDs, one for
each of the sixteen channels,
illuminate “green” when the
amplier circuitry has been turned
on by the Turn-On circuits, and
illuminates “red” to indicate
activation of the amplier’s built-in
protection circuitry

SpeakerCraft SC16-50 Specifications

General

Brand	SpeakerCraft
Model	SC16-50
Category	Amplifier
Language	English
