Page 4 SoundSource Owner’s Manual
Wall Mounting Bracket
with Mounting Screws (2)
Remote Control
with Remote Battery
FM Antenna AM Antenna
SoundSource Unit
This Package Contains
• SoundSource Unit
•
Remote Control (credit card type)
• Remote Battery
• Wall Mounting Bracket
• Mounting Screws (2)
• Power Supply
• FM Antenna
• AM Antenna
• SIR-1.0 (IR Interface Lead)
Optional Accessories (See page 19 for more info)
• SoundSource New Construction Bracket (SSNC) -
Aids in new construction applications by providing a template for the
drywall to be cut around, creating the perfect mounting hole for the SoundSource. (SpeakerCraft P/N CTL01000)
• SoundSource Link System (SSL-A and SSL-B) - Makes connecting auxiliary audio from remote sources easier.
(SpeakerCraft P/
Ns CTL01010 and CTL01020)
• SoundSource FM Modulator (SFM-1.0) - Allows for quick & wireless connection to other sources, such as MP3 players.
(SpeakerCraft P/N CTL01100)
You Will Need
• SoundSource Cable (SSC)
For Power and IR Wiring
14/3, 16/3, 22/2
(SpeakerCraft P/N CTL01030)
• Speaker Wire For Power Connections
3 conductor 14 gauge
3 conductor 16 gauge
You May Need
• External FM Antenna
• External “Long Wire” AM Antenna
•
RCA Cable for Aux Inputs
Power Supply
SIR-1.0 (IR Interface Lead)
Diagram 1:
System Components
OR
To Next Page
