Spearhead Q2000HD - Page 22

Spearhead QHD Flail Mowers
22
Q15S, Q18S & Q21S
REF.
NO
PART NO. DESCRIPTION
1 N/A BODY
2 5770009 GEARBOX
4 5770105A GUARD
5 2770418 BOLT
6 2770434 WASHER
7 5770530 SHAFT Q2000HD
5770531 SHAFT Q2500HD + Q2800
8 1772211 SHAFT - 35MM - 1 X KEYWAY
1772211A SHAFT - 40MM - 1 X KEYWAY
1772211B SHAFT - 35MM - 2 X KEYWAY
10 4772229 KEY
11 4770860EC BEARING - 35MM
4770933EC BEARING - 40MM
12 2770423 BOLT
13 2440447 NUT
14 2770454 WASHER
15 1771513A BRACKET
16 4770920 PULLEY (250MM)
17 4770922 TAPER LOCK
18 4770918 PULLEY (190MM)
19 4770921 TAPER LOCK
20 8777516 CAP
21 1772231B GUARD
22 4770843 BELT
23 1772309 SKID
24 2770422 BOLT
25 8400201 RUBBER 2M
8400200 RUBBER 2.5M
8400199 RUBBER 2.8M
26 1772290 BAR 2M
1772291 BAR 2.5M
1772310 BAR 2.8M
27 2770396 BOLT
28 2770412 NUT
29 1771520A PLATE
30 2770493 BOLT
31 2770457 WASHER
32 1772256A COVER – 2M
1772268A COVER – 2.5 & 2.8M
34 2770469 WASHER
Main Body Assembly
