Spearhead Q2000HD - Page 24

Spearhead QHD Flail Mowers
24
REF.
NO
PART NO. DESCRIPTION
1 1772307 LH PLATE
2 1772307R RH PLATE
3 SA02006 STD ROLLER ASSEMBLY 2.0M
SA02011 LARGE ROLLER ASSEMBLY 2.0M
SA02005 STD ROLLER ASSEMBLY 2.5M
SA02012 LARGE ROLLER ASSEMBLY 2.5M
SA02007 STD ROLLER ASSEMBLY 2.8M
SA02013 LARGE ROLLER ASSEMBLY 2.8M
9 1772305 SHAFT
10 4770872 BEARING
11 2771109 CIRCLIP
12 2777512 CIRCLIP
13 1772306 COVER
14 2770468 GREASE NIPPLE
15 2770425 BOLT
16 2770447 NUT
17 2770454 WASHER
18 4770891 BEARING
19 2771610 CIRCLIP
20 1777850 WASHER
21 2770461 BOLT
22 1777312A COVER
24 7770699 FLAIL
25 180489 BUSH
26 2770600 BOLT
27 05.968.06 NUT
29 2770397 BOLT
30 2770467 GREASE NIPPLE
31 1772303A HOUSING
32 4771122 SEAL
33 2771611 CIRCLIP
34 4770892 BEARING
35 4770893 SLEEVE
36 1772302A HOUSING
2770398 C/SINK BOLT
37 1772311A SEAL HOUSING
38 4771511 WASHER
39 2770443 BOLT
40 1772298A 2.0M LH ROTOR ASSEMBLY
1772298D 2.0M RH ROTOR ASSEMBLY
1772299A 2.5M LH ROTOR ASSEMBLY
1772299D 2.5M RH ROTOR ASSEMBLY
1772301A 2.8M LH ROTOR ASSEMBLY
1772301D 2.8M RH ROTOR ASSEMBLY
41 2770450 BOLT
42 2770436 WASHER
43 2770417 NUT
44 180470 3MM SPACER
Rotor & Roller Assembly
