Spearhead QHD Flail Mowers
28
Hydraulic Headstock Assembly
REF. NO PART NO. DESCRIPTION
1 1772270 HYDRAULIC HEADSTOCK
2 1772271A CLAMP
3 2770519 BOLT
4 2770414 NUT
5 4600120 WEAR PAD
6 6310208 PIN
7 05.281.18 WASHER
8 00.372.01 PIN
9 6310203 PIN
1777434 PTO SUPPORT
6310194 CLIP
11 3580650 RAM – 2M
3580663 RAM – 2.5M & 2.8M
3570650T,W,HP SEAL KIT
12 2770424 BOLT
13 2770417 NUT
14 2770436 WASHER
15 2770471 BOLT
16 2770511 GREASE NIPPLE
17 3760261 HOSE
18 3760262 HOSE
19 3760260 HOSE
20 3460100 ADAPTOR
21 3360080 ADAPTOR
22 3460107 ADAPTOR
23 3260070 WASHER
24 3360074 WASHER
25 3260072 SEAL
26 3750153 QR COUPLING
27 3870500 SLEEVE
28 8770639 TIE
29 3750150 HOSE KIT (COMPLETE)
