Spearhead QHD Flail Mowers
36
Q15S, Q18S & Q21S
REF.
NO
PART NO. DESCRIPTION
5770009 GEARBOX ASSEMBLY
1 5772296 COVER
2 5772341 BEARING
3 5772447 CIRCLIP
4 5772343 SEAL
5 5772297 SHAFT
6 5772344 GEARSET
7 4771606 BEARING
8 PLUG
9 5771435 BEARING
10 5772299 CIRCLIP
11 4771124 OIL SEAL
12 N/A SHIMS
13 5772348 CIRCLIP
14 5771607 BREATHER
15 5772348 CIRCLIP
16 N/A SHIMS
17 5772343 OIL SEAL
18 5772347 CIRCLIP
19 5772340 BEARING
20 5777205 PLUG
1777602 REAR SHAFT GUARD
Gearbox Assembly
