FORK LENGTH SPECIFICATIONS
WARNING! Specialized frames are compatible ONLY with forks that have a specific maximum amount of travel (see table below). Use
of different styled forks or forks with longer travel may result in catastrophic failure of the frame which may result in serious personal
injury or death.
FAMILY MODEL MAX FORK TRAVEL CROWN
EPIC
All 100mm (3.9”) Single
CAMBER
All 110mm (4.3”) Single
CAMBER EVO
All 120mm (4.7”) Single
RUMOR
All 110mm (4.3”) Single
SAFIRE
All 120mm (4.7”) Single
STUMPJUMPER FSR
26” EVO 150mm (5.9”) Single
29 130mm (5.1”) Single
29 EVO 140mm (5.5”) Single
ENDURO
26” 160mm (6.5”) Single
EVO 180mm (7.1”) Single
29” 160mm (6.5”) Single
STATUS
All 200mm (7.9”) Double
DEMO
All 200mm (7.9”) Double
TORQUE SPECS
Torque specs are in-lbf (Nm)
PIVOT (in-lbf / Nm) EPIC CAMBER RUMOR SAFIRE
MAIN (BB)
180 (20) 150 (17) 150 (17) 215 (24.2)
DROPOUT
115 (13) 110 (12.4) 110 (12.4) 95 (10.7)
S-LINK @ FRAME
80 (9) 95 (10.7) 95 (10.7) 110 (12.4)
S-LINK @ SEATSTAY
160 (18) 95 (10.7) 95 (10.7) 110 (12.4)
S-LINK @ CLEVIS
80 (9) -- -- 95 (10.7)
LOWER SHOCK EYE
130 (14.7) 130 (14.7) 130 (14.7) 130 (14.7)
UPPER SHOCK EYE
130 (14.7) 130 (14.7) 130 (14.7) 130 (14.7)
PIVOT (in-lbf / Nm) STUMPJUMPER FSR ENDURO STATUS DEMO
MAIN (BB)
150 (17) 215 (24.2) 215 (24.2) 190 (21.5)
DROPOUT
110 (12.4) 150 (17) 110 (12.4) 190 (21.5)
S-LINK @ FRAME
110 (12.4) 190 (21.5) 215 (24.2) 190 (21.5)
S-LINK @ SEATSTAY
110 (12.4) 190 (21.5) 110 (12.4) 190 (21.5)
S-LINK @ CLEVIS
170 (19.2) 190 (21.5) -- 190 (21.5)
LOWER SHOCK EYE
130 (14.7) 130 (14.7) 190 (21.5) 170 (19.2)
UPPER SHOCK EYE
95 (10.7) 170 (19.2) 190 (21.5) 110 (12.4)
REAR DERAILLEUR
70 (7.9)
FRONT DERAILLEUR
44 (5)
SEAT COLLAR (Bolt style)
45 (5.1)
WATER BOTTLE
25 (2.8)
DOWN TUBE CABLE BATS
30 (3.4)
REAR AXLE
133 (15)
DERAILLEUR HANGER
35 (4)
DERAILLEUR HANGER (Demo)
115 (11.3)
BRAIN MOUNT
55 (6.2)
BRAIN HOUSING GUIDE
6 (0.7)
