5
4.2. GENERAL SPECIFICATIONS
ITEM PART # SPECIFICATION
HEADSET
S182500005
1 1/8” UPPER / 1.5” LOWER DROP-IN BEARINGS
SEAT COLLAR DIAMETER S184700004 38.6mm
SEATPOST DIAMETER 34.9mm
DERAILLEUR HANGER S172600001 HGR MY18 MTB THRU AXLE DER HANGER
BOTTOM BRACKET SHELL BSA THREADED 73mm
CHAINGUIDE TABS ISCG05
REAR HUB SPACING S170200003
AXL MY17 EPIC HT THRU-AXLE 148mm X 12mm
FRONT TIRE 29 x 2.6”
REAR TIRE 29 x 2.3”
MAX TIRE WIDTH 66mm
SHOCK TRAVEL / STROKE 170mm / 205 x 60mm
MAX FORK TRAVEL 170mm
MIN / MAX CHAINRING SIZE
28 - 36t
MIN REAR BRAKE ROTOR SIZE
180mm
WARNING! Specialized frames are compatible ONLY with forks that have a specific
range of travel. Use of different styled forks or forks with longer travel may result in
catastrophic failure of the frame which may result in serious personal injury or death.
WARNING! While the Enduro frame is generally compatible with tires up
to 29 x 2.6, tire dimensions can vary depending on the manufacturer, and
not all forks are designed to accept a larger tire. Always check with the fork
manufacturer regarding required clearances.
CAUTION: Certain rear shocks do not fit inside the frame due to shock shapes.
Verify clearance through the range of travel to ensure there is no interference
with the frame.
CAUTION: Certain 36t chainrings may not have adequate clearance with the
chainstay. If running a 36t chainring, verify spacing and chainline before using it.
4.3. TOOLS REQUIRED
2.5, 3, 4, 5, 6, 8mm ALLEN (HEX) KEYS BLUE THREADLOCKER (LOCTITE 242)
T10, T25 TORX GREEN THREADLOCKER (LOCTITE 603)
TORQUE WRENCH HIGH QUALITY GREASE
HIGH PRESSURE SHOCK PUMP CABLE AND HOUSING CUTTERS
4.4. BOLT SIZE / TOOLS / TORQUE SPECIFICATIONS
WARNING! Correct tightening force on fasteners (nuts, bolts, screws) on your
bicycle is important for your safety. If too little force is applied, the fastener
may not hold securely. If too much force is applied, the fastener can strip
threads, stretch, deform or break. Either way, incorrect tightening force can
result in component failure, which can cause you to lose control and fall.
Where indicated, ensure that each bolt is torqued to specification. After your
first ride, and consistently thereafter, recheck the tightness of each bolt to
ensure secure attachment of the components. The following is a summary of
torque specifications in this manual:
GENERAL TORQUE SPECS:
LOCATION TOOL TORQUE (in-lbf)
TORQUE (Nm)
SEAT COLLAR 4mm HEX 55 6.2
WATER BOTTLE BOSS 3mm HEX 25 2.8
12MM REAR AXLE 6mm HEX 133 15.0
DERAILLEUR HANGER 2.5mm HEX 7 0.8
CHAINSTAY PROTECTOR T25 TORX 7 0.8
DOWN TUBE PROTECTOR T25 TORX / 3mm HEX 7 0.8
SWAT LATCH T10 TORX 0.5
3
0.006
3
ISCG TABS 4mm HEX 55 6.2
3
CAUTION: Tighten SWAT latch screws intermittently until there is no more
wiggling of the latch, then turn each screw another ¼ turn.
