Specialized Enduro Comp - Bearing Specifications for Enduro FSR; Spacer, Axle, and Bolt Specifications

6
CAUTION: Ensure all bolt and axle contact surfaces are clean and greased.
BEARING SPECIFICATIONS
QTY LOCATION DIMENSION BEARING
A
2 FORWARD SHOCK EYE 15 ID x 24 OD x 5 W 6802-2RS
B
1 NON-DRIVE SIDE MAIN PIVOT 15 ID x 26 OD x 7 W 15267-2RS
C
1 DRIVE SIDE MAIN PIVOT 17 ID x 26 OD x 5 W 6803V
D
2 LOWER LINK @ MAIN PIVOT 17 ID x 28 OD x 6 W 17286-2RS
E
2 EXTENSION PIVOT 12 ID x 21 OD x 5 W 6801-2RS
F
2 SEATSTAY @ UPPER LINK PIVOT 12 ID x 21 OD x 5 W 6801-2RS
G
2 UPPER LINK @ SEAT TUBE PIVOT 15 ID x 26 OD x 7 W 15267-2RS
H
2 MID LINK @ LOWER LINK PIVOT 12 ID x 24 OD 6 W 6901-2RS
I
2 MID LINK @ UPPER LINK PIVOT 12 ID x 24 OD 6 W 6901-2RS
J
4 DROPOUT (HORST LINK) PIVOTS 12 ID x 21 OD x 5 W 6801-2RS
SPACER/AXLE/BOLT SPECIFICATIONS
QTY LOCATION / ITEM DIMENSIONS TOOL TORQUE (in-lbf/Nm)
K
1 LOWER LINK SLEEVE
17 ID x 20 OD x 27.5 W
L
1 EXTENSION INNER SPACER
12 ID x 17.6 OD x 5 W
M
2 DROPOUT INNER SPACER
12 ID x 18 OD x 2 W
N
2 MAIN PIVOT NON-DRIVE SIDE SLEEVE
15 ID x 23.5 OD x 27.1 W
O
1 MAIN PIVOT DRIVE SIDE SPACER 17.1 ID x 23 OD x 4.5 W
P
1 MAIN PIVOT DRIVE SIDE SLEEVE
15 ID x 23.5 OD x 27.1 W
Q
1 MAIN PIVOT NON-DRIVE SIDE SPACER 15.1 ID x 23.5 OD x 3 W
R
2 UPPER LINK @ SEAT TUBE SPACER 15.1 ID x 23.5 OD x 3 W
S
2 EXTENSION OUTER SPACER 12.1 ID x 20 OD x 3 W
QTY LOCATION / ITEM DIMENSIONS TOOL TORQUE (in-lbf/Nm)
T
2 MID LINK @ LOWER LINK INNER SPACER 12.1 ID x 20 OD x 3 W
U
4 MID LINK UPPER SPACER 12.1 ID x 20 OD x 3 W
V
4 DROPOUT OUTER SPACER 12 ID x 21 OD x 2.5 W
W
2 UPPER LINK @ SEATSTAY INNER SPACER 12.1 ID x 17.5 OD x 4 W
X
2 UPPER LINK @ SEATSTAY OUTER SPACER 12.1 ID x 20 OD x 3 W
Y
2 FORWARD SHOCK EYE SPACER 10.1 ID x 15 OD x 7.5 W
Z
1 MAIN PIVOT AXLE 15 OD x 82.9 L 8MM HEX
AA
1 MAIN PIVOT BOLT M12 x 6 L 6MM HEX 160 / 18
BB
1 MAIN PIVOT WEDGE M6 x 30 L 4MM HEX 62 / 7
CC
2 UPPER LINK @ SEAT TUBE BOLT M15 x 20 L 8MM HEX 177 / 20
DD
1 MID LINK @ LOWER LINK PIVOT AXLE 12 OD x 61 L
EE
1 MID LINK @ LOWER LINK PIVOT BOLT M8 x 16 L 6MM HEX 160 / 18
FF
1 MID LINK @ LOWER LINK PIVOT SPACER 8.5 ID x 23.5 OD x 6 W
GG
2 MID LINK @ UPPER LINK AXLE 12 OD x 17.5 L
HH
2 MID LINK @ UPPER LINK BOLT M9 x 14 L 5MM HEX 106 / 12
I I
2 DROPOUT (HORST LINK) BOLT M11 (12 OD) x 30 L 6MM HEX 160 / 18
JJ
2 UPPER LINK @ SEATSTAY AXLE 12 OD x 17.5 L
KK
2 UPPER LINK @ SEATSTAY BOLT M9 x 14 L 5MM HEX 106 / 12
LL
2 FLIP CHIP SPACER 8 ID x 15 OD x 6.5 W
MM
1 REAR SHOCK EYE WASHER 8.3 ID x 13 OD x 0.5 W
NN
1 REAR SHOCK EYE BOLT M8 x 29 L 6MM HEX 160 / 18
OO
2 FORWARD SHOCK EYE BOLT M10 x 15 L 6MM HEX 160 / 18
