3.0 TECHNICAL SPECIFICATIONS
4.0 INSTALLATION
4.1 LOCATION
4.1.1 Locate the pump as close to the pool as practical and in accordance with any relevant
regulations or recommendations.
4.1.2 The pump must be installed in a dry and well-ventilated position protected from
the elements.
4.1.3 A clearance of 250mm is required behind the motor for ease of removal and ventilation.
4.1.4 The pump must be installed horizontally up to 3 metres maximum below or 1.5 metres maximum
above the pool water level.
4.1.5 DO NOT store or use gasoline or other ammable gases or liquids in the vicinity of this pump.
DO NOT store pool chemicals near the pump.
4.1.6 Flooding or moisture in the motor voids warranty. Ensure the pump is elevated and
kept dry.
Model Motor
Model Rated
Power (Watts)
Max / Min
head (m)
Magic8 Fasco Motor 806452NTG-A13AC 700 14/4
Magic 11 Fasco Motor 806452PTG-A13AC 1000 13/4
Aqua maxi 300 Fasco Motor 806452PTG-A13AC 1000 13/4
Aqua maxi 400 Fasco Motor 806452QTG-A30AC 1100 15/4
90/230 Fasco Motor 806452PTG-A13AC 1000 12/4
90/350 Fasco Motor 806452QTG-A30AC 1100 13/4
90/400 Fasco Motor 807252RTB-A11AC 1300 15/4
90/500 Fasco Motor 807252STB-A18AC 1500 18/4
90/500 DS Fasco Motor 807281STB-A12AC 1530/290 18/2
43/480 HLS Fasco Motor 807252XTB-A14 2100 23/6
43/480 HNS Fasco Motor 807252XTB-A14 2100 23/6
43/480 LS Fasco Motor 807252XTB-A14 2100 23/6
43/480 NS Fasco Motor 807252XTB-A14 2100 23/6
43/600 LS Fasco Motor 807252XTB-A14 2100 18/6
43/600 NS Fasco Motor 807252XTB - A14 2100 18/6
21/80 32SG Fasco Motor 809252VTB-B14 2770 17/6
80/50 NS Fasco Motor 809252VTB-B14 2770 17/6
80/50GS Fasco Motor 809252VTB-B14 2770 17/6
