Speco HT-INTB8 - Technical Specifications

LOW LIGHT INTENSIFIER / BUILT IN - SELECTABLE TO 128 X
MODEL HT - INTB8
Image Pick-Up Device 1/3" SONY SUPER HAD CCD - 410K
TV System
NTSC
Total Pixels NTSC = 811(H) * 508(V)
Effective Pixels NTSC = 768(H) * 494(V)
Scanning Frequency NTSC = 15.734KHz(H) / 59.94Hz(V)
Scanning System 2:1 Interlaced
Synchronization Internal / Line Lock
Resolution 560 TV Lines
Minimum Illumination 0.002 LUX Intensifier @ 128 X
S / N Ratio More than 50db ( Weight On )
White Balance ATW / AWC / MANUAL ( 1800'K ~ 10,500'K )
Video Output Composite Video 1.0Vp - p75ohm / Test Connection
Electronic Shutter Speed NTSC = Auto / Manual ( 1/60 sec ~ 1/120,000 sec )
OSD Built - In - Controlled by Internal Buttons
SLC( Speco Light Compensation ) Low - Middle - High - Off Selectable
Auto Gain Low - Middle - High - Off Selectable
Reduce Noise Low - Middle - High - Off Selectable
Day & Night ( Color ) On / Auto Selectable ( Electrical )
Sharpness On / Off ( Level Adjustable )
Privacy On / Off ( 4 Programmable Zone )
Power Supply Dual Voltage 12 V DC & 24V AC
Power Comsumption 350mA
Lens DC Auto iris Varifocal Lens ( 2.8mm ~ 12mm )
Operation Temp.
Storage Temp.
Demension 100mm(W) * 125mm(H) * 208mm(D)
Weight Approx. 1400(g)
32
- 10 ~ 50 Deg C., RH 95% Max.
- 20 ~ 60 Deg C., RH 95% Max.
SPECIFICATION
