2 Setup, Connection, and Cabling
16 Epoch 25 L1/L2 GPS System User Guide
20.1 Other system components
The base receiver requires the PacificCrest PDL HPB external radio.
2.1 Rover setup
C
WARNING – The rover uses a rechargeable Lithium Polymer battery. To avoid personal
injury or equipment damage, make sure that you read and understand the Safety
Information on page 3 at the front of this manual.
The following guidelines apply whenever you set up the rover receiver:
• To securely connect a BNC cable, align the cable connector with the antenna
receptacle and then turn the antenna until the antenna fits snugly.
• To securely connect a TNC cable, align the cable connector with the receiver
receptacle and then thread the cable connector onto the receptacle until the
cable fits snugly.
Figure 2.4 on page 17 shows the pole-mounted setup for the receiver. To mount the
receiver on a range pole:
1. Attach the antenna to the GPS receiver and connect the GPS antenna cable to
the Epoch L1/L2 GPS antenna and the rover receiver.
2. Thread the GPS receiver onto the range pole.
3. Attach the controller bracket to the pole.
4. Insert the controller into the bracket.
