Setting SP20 to
Receive
Corrections
After the SP20 has initialized, do the following to set up
the SP20 (see also SPace Settings on page 13 to have a
global view of all the settings you can make in SPace):
• In the status bar, touch .
•Open the CORRECTION INFORMATION tab. You are then
requested to choose between different sources of
corrections:
(1) Check the current status of your RTX subscription on
the Receiver Profile Status view by tapping .
• Choose the desired source of corrections, and then touch
the horizontal right arrow in the lower-right corner of the
screen.
1. If you chose SBAS: The message Setting up application
will appear briefly, followed by the SKYPLOT view (see
below).
2. If you chose NTRIP: The first time you want to make
an NTRIP connection, there is no predefined
connection profile available. Touch the “+” symbol in
the lower-left corner of the screen and then enter the
parameters of your NTRIP provider:
Friendly Name (max 20 chars): Freely choose a convenient
name for this connection profile.
Host Name or IP Address (The host name should contain
a valid domain name.)
Port Number
Touch th e Get Source Table button to list the mount
points available from this provider and select one. If
you remember the name of the mount point you want
to use, you don’t need to acquire the source table: Just
Source of
corrections
Meaning
SBAS Corrections will be received from an SBAS satellite
NTRIP
Corrections will be received from a particular mount point
part of an NTRIP network, via the Internet
DIP Corrections will be received from a base via the Internet
RTX IP
Corrections will be received from a Trimble RTX service
via the Internet (RTX IP mount point (worldwide) or
RTXEU mount point (EU only). A valid subscription to a
Trimble RTX service is required (1).
RTX L-BAND
Corrections will be received from a Trimble RTX service
via an RTX satellite. A valid subscription to a Trimble RTX
service is required (1).
