English
15
technical support requires to do so. Otherwise keep it
disabled. Debug data will be saved as an
ATL_yymmdd_hhmmss.log file stored in folder:
.../Download/ATL Data/
e.g. ATL180524_141126.log created at 2:11:26pm on May 23, 2018.
– Keep NMEA outputs running: When enabled, this option
makes sure all the NMEA messages delivered by the
GNSS receiver to SPace continue to be output while
SPace is running and after SPace has stopped running.
– Help: Touch this line to open the Help page. Use the
Back key on the device to close the Help page.
– About: Touch this line to read the installed SPace
software version.
Monitoring SP20
Operation
Operating Status Screens
The SKYPLOT tab ([1]) shows the current locations of
satellites in the sky.
The SKYPLOT tab ([1]) is a polar diagram showing the location
in the sky of each tracked satellite.
