touch the Enter Mount Point button and type in the name
of the desired mount point.
Then enter your NTRIP credentials (User Name and
Password).
Touch Connect at the bottom of the screen. At this
point, SPace will initiate a network connection to allow
the SP20 to receive corrections from the chosen
NTRIP provider.
3. If you chose DIP: The first time you want to make a DIP
connection, there is no predefined connection profile
available. Touch the “+” symbol in the lower-left
corner of the screen and then enter the parameters of
your DIP provider:
Friendly Name (max 20 chars): Freely choose a convenient
name for this connection profile.
Host Name or IP Address (The host name should contain
a valid domain name.)
Port Number
Touch Connect in the lower part of the screen. At this
point, SPace will initiate a point-to-point network
connection to allow the SP20 to receive corrections
from the chosen static IP address.
4. If you chose RTX IP: Select the Trimble RTX mount
point to connect to RTXIP (for worldwide coverage), or
RTXEU (for European coverage only). You also need a
valid subscription to a Trimble RTX service.
5. If you chose RTK L-BAND: There is no additional
settings required, but you need a valid subscription to
a Trimble RTX service.
NOTE: Next time you turn on the SP20 for a new working
session, the last NTRIP or DIP network connection made
will be re-established automatically, provided you still
have the required environment (modem, Wi-Fi) to
establish a network connection.
SPace Settings • In the status bar, touch .
• Set the following parameters:
– Autostart application at boot: Enabling this parameter
means SPace will be started automatically next time
you power on your SP20. This way, you don’t have
anything else to do at power up, but start your
application as soon as the SP20 is ready to operate. If
you disable this parameter, SPace will run only if you
start it manually or if you start MobileMapper Field.
