Spectracom Corporation EPSILON Switch & Amplifier System E
User’s Manual
4-5
b. Automatic B: Channel B selected with the automatic mode, either
through the front panel switch or through the internet port
c. Forced A: Channel A forced in manual mode, either through the front
panel switch or through the internet port
d. Forced B: Channel B forced in manual mode, either through the front
panel switch or through the internet port
6. Channel selection source: Status of the source selection
a. Network: The front panel switch is locked and the selection mode is
made via the Ethernet port
b. Front panel: The front panel switch is unlocked and the choice of the
channel is made via the front panel switch
Output Channel: Status of all Outputs:
1. Frequency output
a. OK (Green): Frequency inputs are monitored and all frequency outputs
are OK
b. Alarm (Red): Frequency inputs are monitored and at least one
frequency output is failed
c. Disable (gray): Frequency inputs and outputs are not monitored
2. ToD output
a. OK (Green): ToD inputs are monitored and all ToD outputs are OK
b. Alarm (Red): ToD inputs are monitored and at least one ToD output is
failed
c. Disable (gray): ToD inputs and outputs are not monitored
3. 1PPS output
a. OK (Green): 1PPS inputs are monitored and all 1PPS outputs are OK
b. Alarm (Red): 1PPS inputs are monitored and at least one 1PPS output
is failed
c. Disable (gray): 1PPS inputs and outputs are not monitored
