The function of each LED is described in the table below.
2.3.1 XDS560V2 STM LEDs During Boot
When power is applied to the XDS510v2 it will begin booting its OS and provide a
visual indication of its progress and also indicate if booting for normal operation or into
safe mode. The boot manager will go to “Safe Mode” if it detects a problem during OS
boot or a potential hardware problem with the XDS560v2. When in “Safe Mode” you
cannot run CCS instead you can use the Sd560v2Cnfg utility to diagnose the problem
and return to normal boot mode. The following sequences with approximate timings
are provided for reference. From the sequences you can see that it may take the
XDS560v2 around 60 seconds to boot so during this time do not power cycle the unit.
Normal Boot Progress:
POWER........ON time0
ACTIVITY-1...ON time0 + 3 seconds : Linux+Application booting
STATE-2........ON time0 + 39 seconds : FPGA loaded
STATE-3........ON time0 + 41 seconds : Communications application running
ACTIVITY-1...OFF time0 + 41 seconds : Boot process complete
Safe Mode Boot Progress:
POWER........ON time0
ACTIVITY-1...ON time0 + 3 seconds : Linux+Application booting
STATE-3........ON time0 + 4 seconds : Linux boot to Safe Mode
ACTIVITY-3, ACTIVITY-2, STATE-1 Blinking time0 + 41 seconds : Safe Boot process
complete
Table 1: XDS560v2 STM LEDs
LED Name LED Color Function
POWER Green Emulator power indicator
ACTIVITY-3 Red Target to XDS560v2 STM trace activity
ACTIVITY-2 Yellow XDS560v2 STM to host activity
ACTIVITY-1 Green Reserved
STATE-3 Red
On = XDS560v2 STM ready
Off = XDS560v2 STM not ready
STATE-2 Yellow
On = FPGA programmed
Off = FPGA not programmed
STATE-1 Green
On = CCS connected
Off = CCS disconnected
Ethernet Yellow Yellow
Ethernet Link/Activity :
LINKLED- Signal
Ethernet Green Green
Ethernet Collision/Duplex/Speed :
LED1- Signal
