Spectrum 200-H - Quick Start Guide: Hardware Overview; Front Panel Overview; Rear Panel Overview

GB4
Rear
Note: The image may differ from the actual product.
1. Cable In: Connect to a coaxial cable from your service provider.
2. Analog: Use an RCA cable to connect to the TV.
3. Digital: Use an SPDIF cable to connect to the audio system.
4. HDMI: Use an HDMI cable to connect to the high definition TV.
5. Network: Connect a LAN cable.
6. USB: ConnectaUSBstoragedevice(5V500mA).
7. Power : Use the AC adaptor to connect to the power supply.
Front
Note: The image may differ from the actual product.
1. Power: Switches between operation and standby modes.
2. Navigation: Moves the cursor up, down, left or right. Selects a menu or
confirms a selection.
3. Menu: Displays the main menu.
4. USB: ConnectaUSBstoragedevice(5V500mA).
5. Reset: Restores to the factory default setting.
Note: The product information label is on the bottom of the product.
