AR7350 Instruction Manual
The AR7350 full range 7-channel receiver features DSM
®
technology and is
compatible with all Spektrum
™
and JR
®
aircraft radios that support DSM2
®
and
DSMX
®
technology.
Features
• 7-ChannelFullRangeReceiverwithintegratedAS3X
®
technology
• Integratedtelemetry
• TwoX-Busports
• ProgrammablefrommobiledevicesorPC
• Threegyromodes:Off,RateModeandHeadingHold
• Assignablechanneloutputs
Applications
Full range aircraft using up to 7 channels. Not for use in helicopters or aircraft
with full carbon fiber fuselages.
Specifications
Type: DSM Full Range Receiver
Channels: 7
Modulation: DSM2, DSMX
Dimension (WxLxH): 2.1 x 1.15 x 0.55 in (53.5 x 29.1 x 14.1mm)
Weight: 0.93 oz (26.5 g) main receiver
Input Voltage Range: 3.5–12V
Resolution: 2048
Compatibility: All DSM2 and DSMX Aircraft Transmitters and Module Systems
Binding
The AR7350 receiver must be bound to the transmitter before it will operate.
Bindingistheprocessofteachingthereceiverthespeciccodeofthe
transmitter so it will only connect to that specific transmitter.
1. Connect at least one remote receiver to the main receiver.
2. InsertthebindplugintheBINDportonthereceiver.
3. Power the receiver through any open channel port. The orange LED on the
receiver flashes, indicating the receiver is in bind mode. NEVER power the
receiver through a telemetry port.
4. Putthetransmitterinbindmode.BindingiscompletewhentheorangeLED
on the receiver is solid.
5.RemovethebindplugfromtheBIND/PROGportonthereceiverbeforeyou
power off the transmitter and store it in a convenient place.
NOTICE: Remove the bind plug to prevent the system from entering bind
mode the next time the power is turned on.
6. After you set up your model, always rebind the transmitter and receiver to
set the desired failsafe positions.
